【2023 Newest Version OBD2 Car Scanner】This OBD Car Diagnostic Scanner is faster than any Bluetooth or WiFi OBD adapter on the market, it only take 3 seconds to read. This OBD II has Large LCD display (128 x 64 pixels) with contrast adjustment for direct display of test results.
【Classic and portable design】Large LCD display with cable, OBD2 scan tool made of very thick flexible insulation. The portable size allows you to take your travels with you.
【Full OBDII Diagnostic Scanner Function】Automotive code readers easily determine the cause of the engine light, read code, erase code, view freeze frame, I/M ready, vehicle information, data flow, get vehicle speed information, calculate load value, engine coolant temperature, get engine Speed, read and clear error codes and support 5 languages: German, English, Spanish, French, Dutch.
【Easy to Operate】Auto scan tool Get power directly from the OBDII data link connector in the vehicle without any battery or charger. Simply plug in the OBD interface to start diagnosis. We can clearly read the error codes from LCD display. Even a beginner can use this unit to read the error code, find out what the problem is and perhaps fix it.
【Powerful Compatibility for Vehicles】OBD2 Car Scanner supports 9 protocols compatible with more vehicles, including vehicles equipped with next-generation protocols - Control Area Network (CAN).Applicable to 1996 US, 2000 EU and Asian cars, as well as newer OBD II and CAN domestic or imported vehicles. So you don't have to worry about his compatibility.
Say goodbye to expensive automotive repair shop, car engine code reader simple and super easy to use. This little device saves you the trips to your mechanic, lets you decide if it's something you can fix or need more advanced help. Save money and time.
Key Feature:
✅ Reads and clears check engine light codes, both generic and manufacturer-specific, and resets monitor.
✅ Built-in DTC look-up library for manual retrieval and code definition.
✅ I/M Readiness to test misfire, fuel system and Comprehensive component.
✅ Displays all data stream items or selects any item of live data for graphing.
✅ Views freeze frame data and shows vehicle parameters recorded by ECU when an emission-related fault occurs.
Specification:
Product mode: OBDII code reader Product type: V309 Product dimensions: 95x72x22mm/3.7x2.8x0.9in
Product Weight: 147g/0.32lb
Storage temp: -30℃〜60℃
Operating voltage: DC 9〜16V provided via vehicle
Working current: 80mA OBD connector: 16 PIN OBDII
Supports OBD-II protocols:
1. SAE J1850 PWM (41.6Kbaud) 2. SAE J1850 VPW (10.4Kbaud) 3. ISO9141-2(5 baud init, 10.4Kbaud) 4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud) 5. ISO14230-4 KWP (fast init, 10.4 Kbaud) 6. ISO15765-4 CAN (11bit ID, 500 Kbaud) 7. ISO15765-4 CAN (29bit ID, 500 Kbaud) 8. ISO15765-4 CAN (11bit ID, 250 Kbaud) 9. ISO15765-4 CAN (29bit ID, 250 Kbaud)
◆How to get started?
Simply plug into the OBD II port on your car and turn the ignition on and you ready to go.
◆Warm Tips:
1. Must be 16 PIN OBD II port;
2. This OBD2 scanner only supports petrol vehicles;
3. This scanner is valid only for the engine system, not for airbags, ABS and other systems.
◆Why you need OBD2 Scanner ?
This OBD2 car scanner supports Reading DTCs, displaying Live Data, Freeze Frame & Retrieve I/M Ready state etc to figure out the root cause of the Check Engine Light (CEL) and turning it off to help you detect any potential problems.
Package list :
1x Car Engine Diagnostic OBDII Reader
1x User Manual
