Features:
1. Adopted of high quality electronic components, and precision process, ensure for the durability
2. Stable performance and high efficiency conversion rate.
3. Small body and it can provide excellent performance
4. Available in six styles for your choice
5. Suitable for ADC DAC operational amplifier, RS232 RS485 RS422 bus, audio equipment, LCD power supply, instrumentation equipment, MCU board, motor power, instrument multimeter, Wifi router Ethernet equipment
Specification:
Condition: 100percent Brand New
+ 5V:
Input Voltage DC 3 4.5V, Output Dc+ 5V (Deviation+ 5percent )
Maximum Input Current 2A
Maximum Output Current: + Vo Is 1A, Vo Is 200mA
+ 6V:
Input Voltage DC 3 5V, Output Dc+ 6V (Deviation + 5percent )
Maximum Input Current 2A
Maximum Output Current: + Vo Is 1A, Vo Is 200mA
+ 9V:
Input Voltage DC 3.3 8V, Output Dc+ 9 (Deviation + 4percent )
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 800mA, Vo Is 180mA
+ 12V:
Input Voltage DC 3.3 11V, Output Dc+ 12 (Deviation + 4percent )
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 700mA, Vo Is 150mA
+ 15V:
Input Voltage DC3.3 13V, Output Dc+ 15 (Deviation + 4percent )
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 600mA, Vo Is 120mA
+ 24V:
Input Voltage DC3.6 18V, Output Dc+ 24 (Deviation + 4percent )
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 400mA, Vo Is 100mA
Optional Style: 3V 18V to
+
5V, 3V 18V to
+
6V, 3V 18V to
+
9V, 3V 18V to
+
12V, 3V 18V to
+
15V, 3V 18V to
+
24V
Operating temperature Range : 40 +125 celsius
Storage temperature Range : 65 +150 celsius
Weigh: Approx. 4g 0.1oz
Size: Approx. 25 * 16.3 * 6.6mm 1.0 * 0.6 * 0.3in
Package List:
1 * Step up Power Supply
Note:
1. Input voltage can not be greater than the maximum input range
2. Output power can not be greater than the maximum load for a long time
3. Input power must be greater than the output power, because the power consumption of the module itself
4. Due to the diode partial pressure, the voltage of Vo is lower than +Vo
5. In order to obtain a more stable voltage, it is recommended that the output is greater than 15MA
6. Vo cannot be used alone, or no voltage output.But you can just use +Vo
