Feature:
1. Application: Mainly used in marine DC systems as main circuit or branch circuit breakers, truck and bus, commercial and passenger cars, power management systems, RV systems, etc.
2. Secure Using: The circuit breaker has external fireproof, IP67 waterproof, dustproof and explosion proof characteristics. Comes with a UL rated 94V‑0 housing, highly reliable in use.
3. Working Voltage: The maximum working voltage is up to 32V, any battery system below 32V, including 32V, can be used, 1 4in stainless steel stud, surface mount.
4. Meeting Standards: Automatic reset circuit breaker is in line with these standards, AE J553, J1625, J1428 less than 150A , J1171, UL1500, with ignition protection for safe use.
5. Excellent Performance: Simple installation, practical and high performance, superior automatic reset circuit breaker can directly replace the broken or shabby one.
Specification:
Item Type: Circuit Breaker
Material: Thermoset Plastic, UL Class 94V0
Maximum Working Voltage: 32V
Working Temperature: 32 celsius to +82 celsius
Storage Temperature: 34 celsius to +149 celsius
Rated Current: 30A
Maximum Torsion: 1 4in at 100in B (11.3Nm)
Reset Type: T1, Automatic Reset
Meet Standard: AE J553, J1625, J1428 ( less than 150A) J1171, UL1500 (Ignition Protected)
Termination: 1 4in Stainless Steel Stud
Dustproof and Waterproof: IP67
Applicable Scene: All batteries with working voltage below 32V can be used, including 32V
Interrupt Capacity:
2,500A at. 14Vdc (25 200A)
1,500A at. 48Vdc (25 200A)
1,500A at. 14Vdc (225A 300A).
Package List:
1 x Circuit Breaker
Note:
After overload protection, the circuit breaker will automatically reset and restart within about 60 seconds. Due to the large current, if the abnormality is not eliminated, it will bring great danger. Non professionals do not recommend it.
