Adjustable Frequency Range ICL8038 Signal Generator Low Frequency Generator

Features: * Adopt ICL8038 and high-speed operational , with higher for . * Can output sine/triangle/square/forward and reverse sawtooth waveforms. * Frequency range: 5Hz~400kHz; Duty cycle range: 2~95% (adjustable) * Support dual power , no blocking capacitor, for ensure high and low frequency signal distortion. * Adjustable frequency and amplitude. * Frequency adjustment has coarse and fine adjustment functions. * All are through-hole components, easy to install.

Specifications: Product name: Signal generator kit Material: FR4+Acrylic Color: As shown in the picture Size: PCB board size: 81*51mm Supply voltage: 12V~15V Frequency range: 5Hz~400KHz (adjustable) Duty cycle range: 2~95% (adjustable) Low distortion sine wave: 1% Low temperature drift: 50ppm/°C Output triangle wave linearity: 0.1% DC bias range: -7.5V~7.5V Output amplitude range: 0.1V~11VPP (working voltage 12V)

Package Content: 1*Signal generator kit or 1*Signal generator kit (with acrylic shell)

Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
