Feature:
1. MEASURING OBJECT: Clamp meter can accurately measure up to 400A AC DC current, 600V AC DC voltage, resistance, capacitance, conductivity, temperature, diode
2. WIDE APPLICATION: Digital clamp meter multimeter is the perfect troubleshooting tool to help you quickly and safely solve electrical problems in your car, industry or home
3. MULTIPLE FUNCTIONS: Clamp meter with digital backlit LCD display, LED flashlight, liquid and air conditioning port temperature measurement, low power indicator, data hold, true RMS, automatic range, SEL function, automatic shutdown after 10 minutes of inactivity, zero function to reduce data errors affected by the Earth magnetic field and help you get more accurate measurements. Non contact AC voltage detection, all round overload protection
4. CONTACTLESS AND SAFER: Contactless voltage(NCV) detector can easily and quickly determine if there is a voltage without touching any wires. Simply press the NCV button with your thumb. The clamp meter has VFD and LoZ modes to provide more accurate readings
5. WITH BACKLIGHT AND FLASHLIGHT: The AC DC clamp meter has a backlit screen and LED flashlight, so you can see readings when working in dim or low light conditions, such as electrical cabinets, under buildings, behind appliances, and other enclosed places, handy LED flashlights can illuminate dim spaces
Specification:
Item Type: Digital Clamp Meter
Model: HT207D
Material: ABS
Battery: 2 x 1.5V AAA battery(not include)
Basic Parameters:
DC Voltage Resolution (accuracy +0.5percent reading + 5 words):
400mV: 0.1mV
4V: 0.001V
40V: 0.01V
400V: 0.1V
600V: 1V
AC Voltage Resolution (accuracy +0.8percent reading + 5 words):
4V: 0.001V
40V: 0.01V
400V: 0.1V
600V: 1V
DC Current Resolution (accuracy +2.5percent reading + 5 words):
40A: 0.01A
400A: 0.1A
AC Current:
Accuracy:
40~400Hz: +(2.5percent reading + 5 words)
Other: +(3.0percent reading + 10 words)
Resolution:
40A: 0.01A
400A: 0.1A
Resistance Resolution (accuracy +1.0percent reading + 5 words):
400 Ohm : 0.1 Ohm
4k Ohm : 0.001k Ohm
4K Ohm : 0.01k Ohm
400k Ohm : 0.1k Ohm
4M Ohm : 0.001M Ohm
40M Ohm : 0.01M Ohm .
Package List:
1 x Clamp Meter2 x Test Pen1 x Temperature Couple1 x User Manual1 x Storage BagMEASURING OBJECT: Clamp meter can accurately measure up to 400A AC DC current, 600V AC DC voltage, resistance, capacitance, conductivity, temperature, diode
WIDE APPLICATION: Digital clamp meter multimeter is the perfect troubleshooting tool to help you quickly and safely solve electrical problems in your car, industry or home
MULTIPLE FUNCTIONS: Clamp meter with digital backlit LCD display, LED flashlight, liquid and air conditioning port temperature measurement, low power indicator, data hold, true RMS, automatic range, SEL function, automatic shutdown after 10 minutes of in
CONTACTLESS AND SAFER: Contactless voltage(NCV) detector can easily and quickly determine if there is a voltage without touching any wires. Simply press the NCV button with your thumb. The clamp meter has VFD and LoZ modes to provide more accurate readin
WITH BACKLIGHT AND FLASHLIGHT: The AC DC clamp meter has a backlit screen and LED flashlight, so you can see readings when working in dim or low light conditions, such as electrical cabinets, under buildings, behind appliances, and other enclosed places,
